Description
Apogee Electronics 16×16 SE
Apogee Symphony I/O Mk II 16 x16 Special Edition offers the highest quality AD/DA conversion of the Symphony series. Offering the ultimate sonic performance for Dolby Atmos and other Immersive audio applications, 16×16 SE takes advantage of the latest advancements in digital and analog audio technology to offer A/D inputs with 124 dB (A) of dynamic range and a THD+N of -115dB, plus D/A outputs with 128dB (A) of dynamic range and an astonishingly low THD+N of -119dB.
Apogee Electronics 16×16 SE
- Highest quality AD/DA conversion of the Symphony series
- Ultimate sonic performance for Dolby Atmos and other Immersive audio applications
- A/D inputs with 124 dB (A) of dynamic range and a THD+N of -115dB
- D/A outputs with 128dB (A) of dynamic range and a THD+N of -119dB
General
Form Factor
- Internal Card
Converter Type
- AD/DA Converter
Number of Channels
- 16x A/D (at 192 kHz)
- 16x D/A (at 192 kHz)
Display
- None
Maximum Sampling Rate
- 192 kHz / 24-Bit
Number of Microphone Preamps
- None
Expansion Slots
- None
Connectivity
Analog Audio I/O
- 2x DB-25 25-Pin Balanced Line Input
- 2x DB-25 25-Pin Balanced Line Output
Phantom Power
- None
Digital Audio I/O
- 2x RCA Coaxial S/PDIF In/Out
Host Connection / USB
- None
USB (Non-Host)
- None
Sync I/O
- None
Network I/O
- None
MIDI I/O
- None
Wireless Connectivity
- None
Performance
Frequency Response
- 1 Hz to 20 kHz +/-0.05 dB (at 44.1 kHz)
Maximum Input Level
- +24 dBu
Maximum Output Level
- +24 dBu
Impedance
- A/D Converters: 10 Kilohm
- D/A Converters: 50 Ohm
Dynamic Range
- A/D Converters: 124 dBA
- D/A Converters: 128 dBA
THD+N
- A/D Converters: -116 dB / 0.00015% (at 23 dBu)
- D/A Converters: -119 dB / 0.00014% (at 21 dBu)
Digital Audio
Sample Rates
- 1 / 48 / 88.2 / 96 / 176.4 / 192 kHz
Bit Depths
- 24-Bit
Compatibility
OS Compatibility
- None
Included Software
- None
App Compatible
- No
Power
Power Requirements
- PCIe
| CODE | APG-16X16SE |
|---|---|
| Brand | Apogee |
| Weight | 2.400000 |
