CHAUVET DJ GigBAR Move Plus ILS Lighting System (Open Box)

Description

The future of easy lighting synchronization is here with GigBAR Move + ILS. This powerful member of the GigBAR family controls the Integrated Lighting System (ILS), the dynamic lighting technology that provides an advanced, coordinated light show across multiple fixture types. GigBAR Move + ILS can control any ILS-enabled fixture, wired or wirelessly. GigBAR Move + ILS is a 5-in-1 lighting system that includes moving heads, derbies, washes, a laser and strobe effect pre-mounted on a single bar. Easy navigation and access to all the powerful 32-watt moving head functions can be accessed directly from the full-color LCD display and Totem Mode keeps the moving heads focused on the dance floor. Built-in UV LEDs illuminate florescent objects for dazzling blacklight effects. GigBAR Move + ILS gives you individual control of each effect to ensure your show looks the way you need it to, but gone is the need to aim a remote directly at the unit! The included RF remote triggers built-in shows without needing line of sight operation. Other easy control options include stand-alone mode, DMX, or wireless footswitch. The GigBAR Move + ILS package includes a tripod, wireless footswitch, RF remote and FREE carry bags to ensure quick setup.

• DMX Channels : 3, 28, or 50
• DMX Connectors : 3-pin XLR
• Pan and Tilt : 540°/180°

Colors :

• moving head :  9 + open, split colors, continuous scroll at variable speeds

Gobos :

• moving head :  9 + open, continuous scroll at variable speeds

Light Source :

• pars :  3 LEDs hex color RGBAW+UV  6 W 2 A , 50,000 hours life expectancy
• strobe :  4 LEDs cool white  5 W 1.2 A , 50,000 hours life expectancy
• derby :  8 LEDs 2 red, 2 green, 2 blue, 2 white  5 W 2 A , 50,000 hours life expectancy
• Moving head 1 LED cool white  32 W, 3 A , 50,000 hours life expectancy
• Laser 638 nm/30mW red  laser diode, 520 nm/20 mW green  laser diode, 450 nm/ 50 mW blue  laser diode
• Strobe Rate : 0 to 30 Hz

Beam Angle :

• Moving head :  17°
• Pars :  22°
• Strobe :  30°

Field Angle :

• Pars :  33°
• Strobe :  62°

Coverage Angle :

• Derby :  131°
• Laser :  93°
• Fits Tripod Size : 5 in 37.4 mm

Illuminance :

• Pars :  1,205 lux   2 m per par
• Moving head :  5,140 lux   2 m per head
• Strobe :  130 lux   2 m
• Power Linking : 7 units   120 V; 12 units   230 V
• Input Voltage : 100 to 240 VAC, 50/60 Hz auto-ranging

Power and Current :

• 81 W, 1.1 A  120 V, 60 Hz
• 79 W, 0.6 A  230 V, 50 Hz
• 248 W, 1.8 A  230 V, 50 Hz
• Approvals : CE, UKCA, RoHS, FCC, FDA
• Stand Height : 8 ft to 8.3 ft 1.5 to 2.5 m
• Footswitch Operating Frequency : 433 MHz
• Footswitch Max Unobstructed Distance : 100 ft 30.5 m
• Footswitch Battery : 9 V alkaline
