Radial Engineering RX4L Catapult 4-Channel Cat 5 Audio Snake

Description

Send Analog Audio Anywhere That Has Cat 5 and 6 Cable With The Radial Engineering RX4L Catapult 4-Channel Cat 5 Audio Snake

The Catapult RX4L is a four-channel line level splitter and isolator that allows you to split four audio channels and transmit them over a single standard cat5 shielded twisted pair cable. This allows you to split line level signals between three different destinations, either on stage or using a buildings existing Cat 5 or Cat 6 cabling to route the signal. Each unit features line level isolation transformers which help to eliminate buzz and hum caused by ground loops, saving hours of troubleshooting. The RX4L has four direct XLR-M outputs and four isolated XLR-M outputs. It features RJ45 type Ethercon connections with ground lift switches.

Ground lift

Input Connectors:XLR, RJ45

Output Connectors: XLR, RJ45

Audio circuit type:Passive line splitter, transformer based

Frequency response: 7Hz ~ 20KHz

Dynamic range: 140dB

Total harmonic distortion: 0.0007% @ 1kHz

Common Mode Rejection Ratio:>113dB

Maximum Input: +35dBu

Manufacturer: Radial Engineering
Model: CATAPULT RX4L
SKU: I433842-N-0-WHXA
UPC: 676101044405
