Sennheiser SKM 500 G4 (Band GW1)

Description

Powerful handheld transmitter with a lightweight black aluminum housing, increased bandwidth and transmission power, ready to take the world’s biggest live stages. For evolution wireless G4 500 Series systems

• Your choice of Sennheiser‘s renowned state-of-the-art e 935, e 945, e 965 capsules
• Easy and flexible wireless synchronization between transmitter and receiver via infrared
• Up to 32 compatible channels
• Up to 88 MHz bandwidth with 3520 selectable frequen- cies, fully tunable in a stable UHF range
• Ethernet connection for Wireless Systems Manager (WSM) control software for advanced frequency coordi- nation in multi-channel setups
• High RF output power (up to 50 mW, adjustable in three steps 10/30/50) depending on country regulations

RF characteristics

• Modulation : Wideband FM
• Frequency ranges : Gw1: 588 – 608 MHz

Transmission Frequencies

• Max. 2880 frequencies, adjustable in 25 kHz steps
• 20 frequency banks, each with up to 32 factory-pre- set channels, no intermodulation
• 6 frequency banks with up to 32 programmable channels
• Switching bandwidth : up to 72 MHz
• Nominal/peak deviation : ±24 kHz / ±48 kHz
• Frequency stability : ≤ ±15 ppm

RF output power at 50 Ω

• Switchable: Low: typ. 10 mW
• Standard: typ. 30 mW High: typ. 50 mW
• Pilot tone squelch : Can be switched off

AF Characteristics

• Compander system : Sennheiser HDX
• AF frequency response : 80 – 18,000 Hz
• Signal-to-noise ratio (1 mV, peak deviation) : ≥ 115 dBA
• Total harmonic distortion (THD) : ≤ 0.9 %
• Setting range for input sensitivity : 48 dB, adjustable in 6 dB steps

Overall Device

• Temperature range : -10 °C to +55 °C
• Power supply : 2 AA batteries, 1.5 V or BA 2015 accupack
• Nominal voltage : 3 V battery / 2.4 V rechargeable battery
• Current consumption : at nominal voltage: typ. 180 mA with transmitter switched off: ≤ 25 µA
• Operating time : Typically 8 h
• Dimensions : Approx. Ø 50 x 265 mm

CODE	SEN-SKM500G4-GW1
Brand	Sennheiser
Weight	1.100000
